Chevron Wheatstone Project

The Chevron Wheatstone Project stands as one of Australia’s most significant resource developments, featuring an offshore platform that processes natural gas from the Wheatstone and Iago fields. A critical phase of this project involved the load-out of a massive topside structure weighing 45,500 tonnes, which included an 8,500-tonne deck support frame. This monumental task was accomplished using Beldam Crossley’s Crossflon® Skidway System.

Crossflon® Skidway System: Ensuring Smooth Operations

Beldam Crossley’s Crossflon® Skidway System is engineered to facilitate the skidding of heavy structures such as topsides and jackets. The system utilises Crossflon® skidway plates, typically comprising a 2.5mm thick dimpled Crossflon® XF225 sheet bonded to a 3mm thick carbon steel plate. The dimples on the Crossflon® XF225 surface are designed to retain the Crossflon® XF500 lubricant, thereby reducing both static and dynamic friction during load-out operations.

Key Advantages of Crossflon® Skidway Systems:

• Low Coefficient of Friction: Crossflon® PTFE offers one of the lowest coefficients of friction among solid engineered materials, minimising resistance during skidding operations.
• Durability: Crossflon® XF225 is highly resistant to chemicals and weather conditions, ensuring longevity and reliability in various environments.
• Ease of Installation: The skidway plates are designed for straightforward installation, often tack-welded to skid beams in an offset configuration to distribute pressure evenly during load-out or launch operations.

Successful Implementation in the Wheatstone Project

The application of the Crossflon® Skidway System was pivotal in the successful load-out of the 45,500-tonne topside for the Wheatstone Project. The system’s efficiency and reliability contributed significantly to the project’s progress, underscoring Beldam Crossley’s commitment to delivering high-performance solutions for complex engineering challenges.

Check out this video from Chevron, showing the process from start to finish:
